f22light Posted July 6, 2018 Share Posted July 6, 2018 Jake, I couldn't make bootable partition on the SSD when I follow the instruction. and found the EFI back-up folder in the macOS in my E7270. When I use the config.plist and DSDT, SSDT files, the USB was able to boot. Can you let me know if they are fit to my laptop? (FYI, I have put the memory part in the config.plist) boot_ok_EFI.zip Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted July 6, 2018 Moderators Share Posted July 6, 2018 If you can boot with it, then use it. It's files from mottoyin I believe. Link to comment Share on other sites More sharing options...
f22light Posted July 8, 2018 Share Posted July 8, 2018 Dear Jake, I successfully installed HS on my laptop. The main problem was I used newest IntelGraphicsDVMTFixup.kext and Lilu.kext. I could complete with their correct version. Thank you very much. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted July 8, 2018 Moderators Share Posted July 8, 2018 So the newest version broke the install or fixes it? That's not clear... Link to comment Share on other sites More sharing options...
f22light Posted July 9, 2018 Share Posted July 9, 2018 The newest version of IntelGraphicsDVMTFixup.kext is for 10.14 while my macOS version is 10.13. when I used it I couldn’t make it boot. all of your instruction worked when I used it to 1.2.0 instead of 1.2.2 also I used 1.2.3 version of Lili.kext instead of 1.2.4 everythig worked with them. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted July 9, 2018 Moderators Share Posted July 9, 2018 Thanks for the clarification. Link to comment Share on other sites More sharing options...
f22light Posted July 20, 2018 Share Posted July 20, 2018 Hello Jake, I got DW1560 today but failed to make it work. If I need correct DVMT and SSDT, can you help me for that? Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted July 20, 2018 Moderators Share Posted July 20, 2018 post debug file Link to comment Share on other sites More sharing options...
f22light Posted July 21, 2018 Share Posted July 21, 2018 attaching the file. thank you!! debug_21050.zip Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted July 22, 2018 Moderators Share Posted July 22, 2018 Replace files to /EFI/Clover Remove these from /EFi/Clover/driver64UEFI EmuVariableUefi-64.efi Remove these from /L/E FakePCIID.kext FakePCIID_Broadcom_WiFi.kext FakePCIID_Intel_HD_Graphics.kext AppleHDA_ALC293.kext Lilu.kext Repair permissions and rebuild cache e7270_HS_f22light.zip Link to comment Share on other sites More sharing options...
