El Capitan on Latitude 7370

[offficial_florin]

Just out of curiosity: Has anyone of you ever tried to install Mac OS on a Dell Latitude 7370?



I want to buy it and replace my E7450 with it but before I want to be sure if macOS works on it because on my E7450 it works better than on a MacBook Pro!

[Hervé]

Never been mentioned here.

[Jake Lo]

I don't think there's graphics support (HD 515)for Core M processor, you might want to go for the E7270 with the "I" processor (HD520) if you prefer the smaller size laptop.

[Hervé]

'should be supported because that's what the MacBook 2016 models are based on: Core m3/m5/m7 with integrated Intel HD Graphics 515.



It's a pretty slick machine IMO, especially with the HiRes option but I guess performance won't be that great with those little Core m CPUs...

[Jake Lo]

My apologies for not doing a better research. Thanks Hervé. It would be interesting to see how well it'll run MacOS on it.

[128keaton]

Hey folks, I've been tinkering with one of these for a while. I have OS X running on it without working graphics or wifi. I've purchased a BCM94352Z, but haven't made progress to making it work. I've been working on the graphics though, and I cannot get it working! It is driving me up the wall! I have the DVMT preallocated at 64MB and everything! The HD515 graphics are finicky I guess. Does anyone have any suggestions? Thanks!

[Jake Lo]

what platform-id have you tested so far?

have you tried these:

0x191e0000

0x191e0003

[128keaton]

Yes:

FakeID kexts + 0x19020001:  rebooted
FakeID kexts + 0x19120000:  â€œFailed to initialize graphics firmware†+ reboot
FakeID kexts + 0x19120001:  rebooted
FakeID kexts + 0x19130001:  Booted fine, without QE (with core image though!)
FakeID kexts + 0x19160000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x19160002:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x19170001:  rebooted
FakeID kexts + 0x191b0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x191E0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x191E0003:  rebooted
FakeID kexts + 0x19260000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x19260002:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x19260004:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x193b0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x193b0005:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
FakeID kexts + 0x193b0006:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo

0x19020001:  â€œwill fallback to host side scheduling if gr†+ freeze
0x19120000:  â€œFailed to initialize graphics firmware†+ reboot
0x19120001:  IOPCIFamily KP / rebooted
0x19160000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x19160002:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x19170001:  IOPCIFamily KP / rebooted
0x191b0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x191E0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x191E0003:  rebooted
0x19260000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x19260002:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x19260004:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x19320001:  IOPCIFamily KP / rebooted
0x193b0000:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x193b0005:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo
0x193b0006:  â€œFailed to initialize graphics firmware†+ glitchy screen without Apple logo

I have not injected any IntelGFX ids tho

[Jake Lo]

Can you attach you Config file?

Do you have patched DSDT/SSDT?

What SMBIOS are you using?

[128keaton]

MacBookPro11,1

config:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
<key>ACPI</key>
<dict>
<key>DSDT</key>
<dict>
<key>Debug</key>
<false/>
<key>DropOEM_DSM</key>
<false/>
<key>Fixes</key>
<dict>
<key>FixRegions_10000000</key>
<true/>
<key>NewWay_80000000</key>
<true/>
</dict>
<key>Name</key>
<string>DSDT.aml</string>
<key>Patches</key>
<array>
<dict>
<key>Comment</key>
<string>change EHC1 to EH01</string>
<key>Disabled</key>
<false/>
<key>Find</key>
<data>
RUhDMQ==
</data>
<key>Replace</key>
<data>
RUgwMQ==
</data>
</dict>
<dict>
<key>Comment</key>
<string>change EHC2 to EH02</string>
<key>Disabled</key>
<false/>
<key>Find</key>
<data>
RUhDMg==
</data>
<key>Replace</key>
<data>
RUgwMg==
</data>
</dict>
<dict>
<key>Comment</key>
<string>change EHC1 to EH01</string>
<key>Find</key>
<data>
RUhDMQ==
</data>
<key>Replace</key>
<data>
RUgwMQ==
</data>
</dict>
<dict>
<key>Comment</key>
<string>change MEI to IMEI</string>
<key>Disabled</key>
<false/>
<key>Find</key>
<data>
TUVJXw==
</data>
<key>Replace</key>
<data>
SU1FSQ==
</data>
</dict>
</array>
<key>ReuseFFFF</key>
<false/>
</dict>
<key>DropTables</key>
<array>
<dict>
<key>Signature</key>
<string>DMAR</string>
</dict>
<dict>
<key>Signature</key>
<string>MCFG</string>
</dict>
</array>
<key>HaltEnabler</key>
<true/>
<key>SSDT</key>
<dict>
<key>DropOem</key>
<true/>
<key>Generate</key>
<false/>
<key>PluginType</key>
<string>1</string>
</dict>
<key>SortedOrder</key>
<array>
<string>SSDT.aml</string>
<string>SSDT-0.aml</string>
<string>SSDT-1.aml</string>
<string>SSDT-2.aml</string>
<string>SSDT-3.aml</string>
<string>SSDT-4.aml</string>
<string>SSDT-5.aml</string>
<string>SSDT-13.aml</string>
</array>
</dict>
<key>Boot</key>
<dict>
<key>Arguments</key>
<string>slide=0 dart=0 nv_disable=1 kext-dev-mode=1 -v</string>
<key>Debug</key>
<false/>
<key>DefaultVolume</key>
<string>ElCapitan</string>
<key>Legacy</key>
<string>PBR</string>
<key>Secure</key>
<false/>
<key>Timeout</key>
<integer>2</integer>
<key>UseKernelCache</key>
<false/>
<key>XMPDetection</key>
<false/>
</dict>
<key>Devices</key>
<dict>
<key>Audio</key>
<dict>
<key>Inject</key>
<string>1</string>
</dict>
<key>USB</key>
<dict>
<key>AddClockID</key>
<true/>
<key>FixOwnership</key>
<true/>
<key>Inject</key>
<true/>
</dict>
</dict>
<key>DisableDrivers</key>
<array>
<string>Nothing</string>
</array>
<key>GUI</key>
<dict>
<key>Hide</key>
<array>
<string>\EFI\BOOT\BOOTX64.EFI</string>
<string>Windows</string>
</array>
<key>Language</key>
<string>en:0</string>
<key>Mouse</key>
<dict>
<key>DoubleClick</key>
<integer>500</integer>
<key>Enabled</key>
<true/>
<key>Mirror</key>
<false/>
<key>Speed</key>
<integer>8</integer>
</dict>
<key>Scan</key>
<dict>
<key>Entries</key>
<true/>
<key>Legacy</key>
<false/>
<key>Tool</key>
<true/>
</dict>
<key>ScreenResolution</key>
<string>1920x1080</string>
<key>Theme</key>
<string>Latitude</string>
</dict>
<key>Graphics</key>
<dict>
<key>Inject</key>
<dict>
<key>ATI</key>
<false/>
<key>Intel</key>
<true/>
<key>NVidia</key>
<false/>
</dict>
<key>NvidiaSingle</key>
<false/>
<key>ig-platform-id</key>
<string>0x191e0000</string>
</dict>
<key>KernelAndKextPatches</key>
<dict>
<key>AppleRTC</key>
<true/>
<key>AsusAICPUPM</key>
<true/>
<key>Debug</key>
<false/>
<key>ForceKextsToLoad</key>
<array>
<string>\System\Library\Extensions\IONVMeFamily.kext</string>
</array>
<key>KernelCpu</key>
<false/>
<key>KernelHaswellE</key>
<false/>
<key>KernelLapic</key>
<false/>
<key>KernelPm</key>
<true/>
<key>KextsToPatch</key>
<array>
<dict>
<key>Comment</key>
<string>HD 520 HDMI</string>
<key>Find</key>
<data>
AgQKAAAEAAA=
</data>
<key>Name</key>
<string>AppleIntelSKLGraphicsFramebuffer</string>
<key>Replace</key>
<data>
AgQKAAAIAAA=
</data>
</dict>
<dict>
<key>Comment</key>
<string>Enable Trim on SSD</string>
<key>Find</key>
<data>
QVBQTEUgU1NE
</data>
<key>Name</key>
<string>IOAHCIBlockStorage</string>
<key>Replace</key>
<data>
AAAAAAAAAAAA
</data>
</dict>
<dict>
<key>Comment</key>
<string>AppleHDA ALC 293 #3</string>
<key>Find</key>
<data>
hQjsEA==
</data>
<key>Name</key>
<string>AppleHDA</string>
<key>Replace</key>
<data>
AAAAAA==
</data>
</dict>
<dict>
<key>Comment</key>
<string>Hand-off (10.11)</string>
<key>Find</key>
<data>
SIX/dEdIiwc=
</data>
<key>Name</key>
<string>IOBluetoothFamily</string>
<key>Replace</key>
<data>
Qb4PAAAA60Q=
</data>
</dict>
<dict>
<key>Comment</key>
<string>AppleHDA ALC 293 #1</string>
<key>Find</key>
<data>
hBnUEQ==
</data>
<key>Name</key>
<string>AppleHDA</string>
<key>Replace</key>
<data>
kwLsEA==
</data>
</dict>
<dict>
<key>Comment</key>
<string>change 15 port limit to 30 in AppleUSBXHCIPCI</string>
<key>Find</key>
<data>
g72M/v//EA==
</data>
<key>Name</key>
<string>AppleUSBXHCIPCI</string>
<key>Replace</key>
<data>
g72M/v//Hw==
</data>
</dict>
<dict>
<key>Comment</key>
<string>External icons patch</string>
<key>Find</key>
<data>
RXh0ZXJuYWw=
</data>
<key>Name</key>
<string>AppleAHCIPort</string>
<key>Replace</key>
<data>
SW50ZXJuYWw=
</data>
</dict>
<dict>
<key>Comment</key>
<string>AppleHDA ALC 293 #2</string>
<key>Find</key>
<data>
hAjsEA==
</data>
<key>Name</key>
<string>AppleHDA</string>
<key>Replace</key>
<data>
AAAAAA==
</data>
</dict>
<dict>
<key>Comment</key>
<string>Broadcom 5Ghz US</string>
<key>Find</key>
<data>
QYP8/3QsSA==
</data>
<key>Name</key>
<string>AirPortBrcm4360</string>
<key>Replace</key>
<data>
ZscGVVPrKw==
</data>
</dict>
<dict>
<key>Comment</key>
<string>AppleHDA #4</string>
<key>Find</key>
<data>
gxnUEQ==
</data>
<key>Name</key>
<string>AppleHDA</string>
<key>Replace</key>
<data>
AAAAAA==
</data>
</dict>
<dict>
<key>Comment</key>
<string>HD 520 HDMI # 2</string>
<key>Find</key>
<data>
AQUJAAAEAAA=
</data>
<key>Name</key>
<string>AppleIntelSKLGraphicsFramebuffer</string>
<key>Replace</key>
<data>
AQUJAAAIAAA=
</data>
</dict>
<dict>
<key>Comment</key>
<string>SecondStagePatch 10.11</string>
<key>Find</key>
<data>
AQAAdRc=
</data>
<key>Name</key>
<string>IOGraphicsFamily</string>
<key>Replace</key>
<data>
AQAAdBc=
</data>
</dict>
<dict>
<key>Comment</key>
<string>SecondStagePatch 10.12</string>
<key>Find</key>
<data>
AQAAdSU=
</data>
<key>Name</key>
<string>disabled:IOGraphicsFamily</string>
<key>Replace</key>
<data>
AQAA6yU=
</data>
</dict>
</array>
</dict>
<key>RtVariables</key>
<dict>
<key>BooterConfig</key>
<string>0x28</string>
<key>CsrActiveConfig</key>
<string>0x67</string>
</dict>
<key>SMBIOS</key>
<dict>
<key>BiosReleaseDate</key>
<string>10/18/13</string>
<key>BiosVendor</key>
<string>Apple Inc.</string>
<key>BiosVersion</key>
<string>MBP112.88Z.0138.B02.1310181745</string>
<key>Board-ID</key>
<string>Mac-3CBD00234E554E41</string>
<key>BoardManufacturer</key>
<string>Apple Inc.</string>
<key>BoardType</key>
<integer>10</integer>
<key>ChassisAssetTag</key>
<string>MacBook-Aluminum</string>
<key>ChassisManufacturer</key>
<string>Apple Inc.</string>
<key>ChassisType</key>
<string>08</string>
<key>Family</key>
<string>MacBook Pro</string>
<key>Manufacturer</key>
<string>Apple Inc.</string>
<key>Mobile</key>
<true/>
<key>ProductName</key>
<string>MacBookPro11,1</string>
<key>SerialNumber</key>
<string>C02KRULYFD56</string>
<key>Trust</key>
<false/>
<key>Version</key>
<string>1.0</string>
</dict>
<key>SystemParameters</key>
<dict>
<key>InjectKexts</key>
<string>Yes</string>
<key>InjectSystemID</key>
<true/>
<key>NoCaches</key>
<true/>
</dict>
</dict>
</plist>
