howoarang Posted November 28, 2016 Author Share Posted November 28, 2016 Ok here it is:Internal display at 1920x1080 is on LVDS-1External display at 3840x2160 is on DP-2 (Dell 4K P2415q)Tested on GParted Linux Link to comment Share on other sites More sharing options...
howoarang Posted November 29, 2016 Author Share Posted November 29, 2016 And about black screen... To properly boot osx on Dell M4800 must be SMBIOS configured like this: In Osx El. Capitan, Yosemie or Maverick, the SMBIOS in Clover is configured to Macbook Pro 11.3 or iMac 14,2 In Osx Sierra it must be iMac 14,2. With Macbook Pro 11,3 cause black sceen. 2 Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 29, 2016 Moderators Share Posted November 29, 2016 You can also use SMBIOS MBP11,2 but replace board-id with that of iMac14,2 or even MBA6,2 2 Link to comment Share on other sites More sharing options...
Administrators Bronxteck Posted November 29, 2016 Administrators Share Posted November 29, 2016 you can check this and maybe it helps. you have to read through the comments to get some info though https://pikeralpha.wordpress.com/2016/10/11/black-screen-tip-of-the-day/ 1 Link to comment Share on other sites More sharing options...
tudt949 Posted December 1, 2016 Share Posted December 1, 2016 Ok here it is: Internal display at 1920x1080 is on LVDS-1 External display at 3840x2160 is on DP-2 (Dell 4K P2415q) Tested on GParted Linux Screen_connector.jpg Has a miss take. You can disable optimus on your M4800 and testing again? If the same result, you're lucky man! This Laptop is easy to config & install new macOS more than mine. Thanks! Link to comment Share on other sites More sharing options...
howoarang Posted December 1, 2016 Author Share Posted December 1, 2016 Hi, the test above is with Disabled Optimus in BIOS.If you need, I can test it again with Enabled Optimus, but I think, there will be only internal screen at 1920x1080 working, because Intel HD4600 GPU doesn't support external dispaly on this mobile workstation. I've tested it some days ago on Windows.Here is topic from official dell.com:"nVidia with Optimus Graphic""Systems equipped with Optimus technology have nVidia Graphics plus Intel integrated graphics this allow for a configuration of up to 4 displays:2 digital displays on nVidia using DVI or DP on the ARP or HDMI on the systems.The LCD and a VGA display on Intel." Link to comment Share on other sites More sharing options...
howoarang Posted December 1, 2016 Author Share Posted December 1, 2016 But I tested again and now with Optimus enabled, as you ask, and there is different result:Internal display is connected to eDPExternal display I leave connected to Laptop, but it is showing that no other display is conected. CONCLUSION: On Dell Precision M4800 (with nVidia GPU) there are 2 choices about display connection: 1. With Switchable Graphics Enabled, Internal display is connected via eDP port, and no other digital ports like HDMI or DP works 2. With Switchable Graphics Disabled, Internal display is connected via LVDS, and external display can be connected via HDMI or DP port. So this choice is better for Hackintosh 1 Link to comment Share on other sites More sharing options...
tudt949 Posted December 5, 2016 Share Posted December 5, 2016 (edited) But I tested again and now with Optimus enabled, as you ask, and there is different result: Internal display is connected to eDP External display I leave connected to Laptop, but it is showing that no other display is conected. CONCLUSION: On Dell Precision M4800 (with nVidia GPU) there are 2 choices about display connection: 1. With Switchable Graphics Enabled, Internal display is connected via eDP port, and no other digital ports like HDMI or DP works 2. With Switchable Graphics Disabled, Internal display is connected via LVDS, and external display can be connected via HDMI or DP port. So this choice is better for Hackintosh Can you share your clover configuration file? My M4800 has the same hw parts as yours, but always get black screen when disabled Optimus. I still can't boot to install sierra. Thank you so much! Edited December 18, 2016 by tudt949 Link to comment Share on other sites More sharing options...
howoarang Posted December 5, 2016 Author Share Posted December 5, 2016 Hi, ok, I can share my config when I come home. But my system doesn't boot to osx with enabled optimus. I tested enabled optimus only with linux. Link to comment Share on other sites More sharing options...
NaXx Posted December 5, 2016 Share Posted December 5, 2016 Hi ! I will try to install Sierra today with your config on your other topic howoarang and with informations here. And I will disable optimus at the moment. I'm on i7-4900MQ / Nvidia Quadro K2100M I will inform you during the day Link to comment Share on other sites More sharing options...
