Moderators Jake Lo Posted November 26, 2017 Moderators Share Posted November 26, 2017 Last I heard touch-base doesn't support I2C connection Link to comment Share on other sites More sharing options...
hus2020 Posted November 27, 2017 Share Posted November 27, 2017 Oh is it. I thought it was serial or usb. It tempted me to try since the model 9q33 is listed on their website, and their system generated a specific driver on my request. Anyway, its not super important. I am happy with conventional keyboard and mouse operation. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 27, 2017 Moderators Share Posted November 27, 2017 Think you're right, there's not I2C devices in this system. Could be an USB issue...check under USB, see if the touchscreen is detected or under preferences, you'll see something call Ink..I think. Could also be the OP's doesn't have touchscreen on his system...so the DSDT/SSDT might not have the patch for it. You could extract your DSDT/SSDT from your system and I'll patch them for you. Just attach the Origin folder after you select the F4 key during boot. Also list your BIOS version. Link to comment Share on other sites More sharing options...
hus2020 Posted November 27, 2017 Share Posted November 27, 2017 Hey Jake, under system info, for usb 2.0 bus, then only think I am unsure is Intel ® Sensor Solution. Not sure if this is what the touchscreen is interacting at. Anyways, for your review, I am attaching my origin folder. My bios is A8. See if you can find a reference to the touch screen controller. Do let me know if any further detail(s) are required. Thank you. origin.zip Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 27, 2017 Moderators Share Posted November 27, 2017 @hus2020 Try this for touchscreen. There's an extra SSDT, but not sure if it makes a difference. Replace Config and DSDT/SSDT into /EFI/Clover/ACPI/Patched Post IOReg IORegistryExplorer_v2.1.zip after replacing the files for review 9Q33_touchscreen_A08.zip Link to comment Share on other sites More sharing options...
jones333333 Posted November 27, 2017 Author Share Posted November 27, 2017 Hey Guys, I also got the touchscreen version of this XPS but i didn't suspected that it could be working Under OSX! Jake Lo , may I ask you if you could provide me the fixes that you used to patch my DSDT. I really into Learning this whole DSDT and SSDT story and I think that I could learn a lot from your work! It could be also very usefull if I need to recreate my DSDT in the future. Thanks in advance for this. @ hus2020 I think that we have the same configuration of this laptop. How do you find the machine performances ? I am personally amazed by this device! It's for now, the best hackintosh laptop that I could use, it feels really like a real MAC. I also got a E7440 which is working very well but this XPS has something special in the feeling that it provides. Really good surprise. I still need to get my hand on a good WIFI/BT combo card for this model and it will be perfect Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 27, 2017 Moderators Share Posted November 27, 2017 sure, but I won't get into too much details because there's a lot involved and you need to understand what to patch for and why... The following patches are mostly from Rehabman's GitHub https://github.com/RehabMan/Laptop-DSDT-Patch, you might need to make some modification on some of his patches for your needs. 1) you need to decompile the raw files together (found in /EFI/Clover/ACPI/Origin), just need the DSDT plus all the SSDT*, leaving out the rest iasl -da -dl *.aml 2) after that you just patch the DSDT and the SSDT without the xx, i.e. SSDT-5x.aml, etc etc. those can be left out from the final results 3) patch all the rest of the SSDT with these common patches, not all will apply Rename _DSM to XDSM Rename GFX0 to IGPU Rename B0D3 to HDAU Remove _PSS placeholder Haswell HD 4600 Yosemite 4) Patch DSDT Rename _DSM to XDSM Rename GFX0 to IGPU Fix ADBG Error Add IMEI Fix_WAK Arg0 v1 Fix Mutex with non-zero SyncLevel Haswell LPC HPET Fix IRQ Fix OS Check Fix (Windows 7) RTC Fix Shutdown Fix SmBUS Fix USB3_PRW 0x6D (instant wake) [bAT] Dell Vostro 15xx Rename B0D3 to HDAU Audio Layout 3 NullEthernet Patch 5) Recompile back to *.aml iasl -ve *.dsl 6) Copy the patched files to /EFI/Clover/ACPI/Patched Add the names to the SSDT SortedOrder, enable DropOEM of Config file Hope that's enough info for you to get started. Link to comment Share on other sites More sharing options...
hus2020 Posted November 28, 2017 Share Posted November 28, 2017 Hi Jones, I agree with you. By far this is my most complete hackintosh ever. You know, I had shelved this computer for almost a year, since I had cpu throttle issues on Windows, and all windows version I tried made the cpu fan run louder and that was worry-some. Trying out hackintosh, and seeing it work so well, it gave a new life to this machine and put it to good use again. My sincerest regards to Jake Lo for being super awesome and so helpful in helping me set this machine up and running so smoothly. I'm struggling now to get hackintosh running properly on my other laptop the Lenovo x260, and I think I know who to look for help and guidance. Link to comment Share on other sites More sharing options...
hus2020 Posted November 28, 2017 Share Posted November 28, 2017 Dear Jake, Please find attached the IOReg file as requested after applying the new config and dsdt/ssdt files. Thank you. IOReg_XPS12.zip Link to comment Share on other sites More sharing options...
jones333333 Posted November 28, 2017 Author Share Posted November 28, 2017 Jake Lo, thanks a lot for all these infos! hus2020, do you already found a good WIFI/BT card replacement for this model ? I think that our best choice would be the Dell DW1560 as Jake Lo said in an earlier post but these are generally out of stock on the different sites: Link to comment Share on other sites More sharing options...
