spidey123 Posted October 20, 2016 Author Share Posted October 20, 2016 Hi guys, I have actually updated to the newest Clover on my internal drive I think I didn't explain myself properly, thats how I finished the Sierra Installation on the External Drive The problem is though, everytime I want to test Sierra I need to go back in to my internal Clover EFI/CLOVER/Kexts and replace the VoodooPS2Controller.kext and the newer Kext that stops kernel panic, doesn't work well at all in either El Capitan. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted October 20, 2016 Moderators Share Posted October 20, 2016 You can also install Clover to your External drive with files for Sierra. When you launch Cloverxx.pkg, select change install location and select the external drive, then customize to set your option. Reboot system. Select F12 during boot and select boot from your external USB drive and it'll load Clover from that drive. Link to comment Share on other sites More sharing options...
spidey123 Posted October 21, 2016 Author Share Posted October 21, 2016 Oh, I didn't even think about that. Ok thanks Jake Lo I will give that a try for sure. Thanks my friend. Link to comment Share on other sites More sharing options...
spidey123 Posted October 21, 2016 Author Share Posted October 21, 2016 Worked like a charm Jake Lo Now if I could only figure out how to get the audio working. I know I need to add the patch with Clover Config, but what I don't know is if the two kexts (AppleHDA and AppleHDAIDT) need any tweaks done to them too and also where to install them. The way I had it in El Capitan was I had them both installed in my EFI/Clover/Kexts/Other and then AppleHDA was also installed into S/L/E overwriting the Vanilla version. I never had to install the AppleHDAIDT to S/L/E Bit puzzled. Going to keep testing. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted October 21, 2016 Moderators Share Posted October 21, 2016 AppleHDA should be vanilla in /S/L/E and AppleHDAIDT should be install to /S/L/E or /L/E. Should have layout-id set to 12 or (hex 0x0C) in DSDT or 12 in Config.plist under device/audio. If you installed AppleHDA overwriting the vanilla kext and you have audio in El Capitan, then it means you have a patched AppleHDA instead of using the dummyHDA (AppleHDAIDT) + hot patches in Config. Link to comment Share on other sites More sharing options...
Administrators Hervé Posted October 21, 2016 Administrators Share Posted October 21, 2016 Patched AppleHDA kexts from older versions such as Mavericks or Yosemite worked in El Capitan. This no longer applies with Sierra. So you'll have to patch Sierra vanilla AppleHDA or use the IDT definition kext + Clover on-the-fly patches described by Jake. Link to comment Share on other sites More sharing options...
spidey123 Posted October 21, 2016 Author Share Posted October 21, 2016 Ok thanks guys. I'll see if I can remember how to patch my AppleHDA from Sierra. I patched my own before, its been a while so I have to re-read how to do it. Or just add the patch with clover config and install the AppleHDAIDT kext into S/L/E Again thanks for the help guys. Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted October 21, 2016 Moderators Share Posted October 21, 2016 You can just install AppleHDAIDT, use the hot patches found in my bootpack here. Also need to add a new one for Sierra AppleHDA find 8A19D411 replace 00000000 Link to comment Share on other sites More sharing options...
spidey123 Posted October 21, 2016 Author Share Posted October 21, 2016 thanks jake lo. I set the layout ID to 12 in my DSDT. I have also downloaded your boot pack. Ok I'll add that last patch with clover config. Thanks to you and everyone else for helping. Hopefuly in a bit I'll have sound up and running. Link to comment Share on other sites More sharing options...
Administrators Hervé Posted October 22, 2016 Administrators Share Posted October 22, 2016 Details of the AppleHDA patch are here. Link to comment Share on other sites More sharing options...
