murad3994 Posted November 1, 2017 Author Share Posted November 1, 2017 No, but I will install Windows and also check/update SSD firmware version. it only has Intel HD Graphics 520 Link to comment Share on other sites More sharing options...
murad3994 Posted November 1, 2017 Author Share Posted November 1, 2017 SSD firmware version was already up to date = 20005A00. Just installed Windows 10, and something weird happened! I had to switch to Legacy mode in order to continue Windows installation from the M.2 SSD. Although it booted and installed fine from USB in UEFI mode Edit: Windows now booting from UEFI, with same BIOS settings as if it was Hackintosh. Link to comment Share on other sites More sharing options...
Administrators Bronxteck Posted November 2, 2017 Administrators Share Posted November 2, 2017 what i wanted to know was if you had windows installed because it can cause install issues with sierra. ok so these errors are on the usb installer. so are you using usb2 thumb drive or usb3 maybe switching the type of usb might help. it must be something we are overlooking because others have installed fine. Link to comment Share on other sites More sharing options...
murad3994 Posted November 3, 2017 Author Share Posted November 3, 2017 I had SSD wiped from BIOS prior hackintoshing i only have usb3 thumb drives, and all the ports on the laptop are usb3 as well. i think i will give Sierra a try. but i don't know where to get it from! Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 4, 2017 Moderators Share Posted November 4, 2017 Enable FixHeaders_20000000 Link to comment Share on other sites More sharing options...
murad3994 Posted November 4, 2017 Author Share Posted November 4, 2017 finally was able to reach install screen but SSD is not shown! using attached config.plist kexts from murad3994.zip (thanks to Jake) ACPI is default (contains three empty folders) Edit: I added ACPI from murad3994.zip > still no ssd in disk utility. About the config.plist file, I have no idea what the options are for. I just copycat from another website, and also from the one provided by Jake. If I add the config file from murad3994.zip, it will not show usb installer in the boot menu config.plist.zip Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 4, 2017 Moderators Share Posted November 4, 2017 try this You need either HFSPlus.efi or VboxHFS-64.efi in /EFI/Clover/drivers64UEFI config.plist.zip Link to comment Share on other sites More sharing options...
murad3994 Posted November 4, 2017 Author Share Posted November 4, 2017 VboxHFS-64.efi was already in drivers64UEFI folder, so I replaced it with HFSPlus.efi. I also replaced config.plist with the one you provided. and still doesn't show the SSD. it shows External > USB installer (30GB) Disk Image > OS X Base System (2.01GB) Link to comment Share on other sites More sharing options...
Moderators Jake Lo Posted November 4, 2017 Moderators Share Posted November 4, 2017 there's a drop down arrow on the top left of Diskutil ( new for HS). Click on it to show all disk Link to comment Share on other sites More sharing options...
murad3994 Posted November 4, 2017 Author Share Posted November 4, 2017 Yes, I already tried that. I remember when I started using "an alternative to clover", I could see about 5 drives in its boot menu, but never got to the installation screen. And when I was able to boot to the installation screen, there were only two drives in boot menu; the usb installer and ‘Boot Windows EFI from EFI’ or sth like that. Link to comment Share on other sites More sharing options...
