DW5570: how can i use the WWAN under High Sierra?

wojciech679

By wojciech679
in Modems/WWAN modules

 Share

Recommended Posts

viking1304 Staff Sergeant

viking1304

Posted
Posted

Please go to System Preferences / Network, select your WWAN card, click on Advanced and go to PPP tab. Select Use verbose logging, apply everything and try to connect.



Find and send your /var/log/ppp.log after that.



Let's see what we can figure out from there.

Link to comment
Share on other sites
  • Replies 27
  • Created
  • Last Reply

Top Posters In This Topic

Popular Days

Top Posters In This Topic

Popular Days

Popular Posts

viking1304
viking1304

I made a kext for HS based on what Hervé suggested to me, but card didn't work until I changed USBCOMP mode.   You absolutely need to change card's USBCOMP mode (from Linux or Windows), since card ca

Hervé
Hervé

You can try and add the usual WWAN patch tuned for the DW5570, either into FakeSMC or in CellPhoneHelper; just not in both...   You can refer to the guidance and general principles detailed in this

viking1304
viking1304

I hope that admins would not treat this post as off-topic, since purpose of this post is to help you and probably other people to change USBCOMP mode on their WWAN cards in order to use them under mac

Posted Images

wojciech679 Private First Class

wojciech679

Posted
  • Author
Posted

My ppp.log

http://www50.zippyshare.com/v/EFzpMpXb/file.html



Tue Jan 23 01:02:48 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:02:48 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:02:49 2018 : Apple Base Script.ccl Version 3.3
Tue Jan 23 01:02:59 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:02:59 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:02:59 2018 : Connect script failed
Tue Jan 23 01:03:41 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:03:41 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:03:42 2018 : Apple Base Script.ccl Version 3.3
Tue Jan 23 01:03:52 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:03:52 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:03:52 2018 : Connect script failed
Tue Jan 23 01:04:06 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:04:06 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:04:07 2018 : Apple Base Script.ccl Version 3.3
Tue Jan 23 01:04:17 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:04:17 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:04:17 2018 : Connect script failed
Tue Jan 23 01:04:27 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:04:27 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:04:28 2018 : Apple Base Script.ccl Version 3.3
Tue Jan 23 01:04:38 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:04:38 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:04:38 2018 : Connect script failed
Tue Jan 23 01:05:00 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:05:00 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:05:01 2018 : Apple Base Script.ccl Version 3.3
Tue Jan 23 01:05:11 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:05:11 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:05:11 2018 : Connect script failed
Tue Jan 23 01:06:02 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:06:02 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:06:13 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:06:13 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:06:13 2018 : Connect script failed
Tue Jan 23 01:06:46 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:06:46 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:06:57 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:06:57 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:06:57 2018 : Connect script failed
Tue Jan 23 01:07:13 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:07:13 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:07:24 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:07:24 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:07:24 2018 : Connect script failed
Tue Jan 23 01:07:59 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:07:59 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:08:10 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:08:10 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:08:10 2018 : Connect script failed
Tue Jan 23 01:08:23 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:08:23 2018 : publish_entry SCDSet() failed: Success!
Tue Jan 23 01:08:34 2018 : Modem error; the modem is not responding.
Tue Jan 23 01:08:34 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Tue Jan 23 01:08:34 2018 : Connect script failed
Thu Jan 25 22:16:07 2018 : publish_entry SCDSet() failed: Success!
Thu Jan 25 22:16:07 2018 : publish_entry SCDSet() failed: Success!
Thu Jan 25 22:16:18 2018 : Modem error; the modem is not responding.
Thu Jan 25 22:16:18 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Thu Jan 25 22:16:18 2018 : Connect script failed
Fri Jan 26 00:26:32 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:26:32 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:26:33 2018 : Apple Base Script.ccl Version 3.3
Fri Jan 26 00:26:43 2018 : Modem error; the modem is not responding.
Fri Jan 26 00:26:43 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 00:26:43 2018 : Connect script failed
Fri Jan 26 00:27:51 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:27:51 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:27:52 2018 : Apple Base Script.ccl Version 3.3
Fri Jan 26 00:28:02 2018 : Modem error; the modem is not responding.
Fri Jan 26 00:28:02 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 00:28:02 2018 : Connect script failed
Fri Jan 26 00:37:47 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:37:47 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:37:48 2018 : Apple Base Script.ccl Version 3.3
Fri Jan 26 00:37:58 2018 : Modem error; the modem is not responding.
Fri Jan 26 00:37:58 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 00:37:58 2018 : Connect script failed
Fri Jan 26 00:38:25 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:38:25 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 00:38:36 2018 : Modem error; the modem is not responding.
Fri Jan 26 00:38:36 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 00:38:36 2018 : Connect script failed
Fri Jan 26 10:24:45 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:24:45 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:24:56 2018 : Modem error; the modem is not responding.
Fri Jan 26 10:24:56 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 10:24:56 2018 : Connect script failed
Fri Jan 26 10:32:02 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:32:02 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:32:03 2018 : Apple Base Script.ccl Version 3.3
Fri Jan 26 10:32:13 2018 : Modem error; the modem is not responding.
Fri Jan 26 10:32:13 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 10:32:13 2018 : Connect script failed
Fri Jan 26 10:57:39 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:57:39 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 10:57:50 2018 : Modem error; the modem is not responding.
Fri Jan 26 10:57:50 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 10:57:50 2018 : Connect script failed
Fri Jan 26 11:10:07 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:07 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:18 2018 : Modem error; the modem is not responding.
Fri Jan 26 11:10:18 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 11:10:18 2018 : Connect script failed
Fri Jan 26 11:10:23 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:23 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:34 2018 : Modem error; the modem is not responding.
Fri Jan 26 11:10:34 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 11:10:34 2018 : Connect script failed
Fri Jan 26 11:10:43 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:43 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:10:54 2018 : Modem error; the modem is not responding.
Fri Jan 26 11:10:54 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 11:10:54 2018 : Connect script failed
Fri Jan 26 11:11:01 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:11:01 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:11:12 2018 : Modem error; the modem is not responding.
Fri Jan 26 11:11:12 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 11:11:12 2018 : Connect script failed
Fri Jan 26 11:19:02 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:19:02 2018 : publish_entry SCDSet() failed: Success!
Fri Jan 26 11:19:13 2018 : Modem error; the modem is not responding.
Fri Jan 26 11:19:13 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Fri Jan 26 11:19:13 2018 : Connect script failed
Sat Jan 27 13:08:23 2018 : publish_entry SCDSet() failed: Success!
Sat Jan 27 13:08:23 2018 : publish_entry SCDSet() failed: Success!
Sat Jan 27 13:08:34 2018 : Modem error; the modem is not responding.
Sat Jan 27 13:08:34 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Sat Jan 27 13:08:34 2018 : Connect script failed
Wed Jan 31 18:25:41 2018 : publish_entry SCDSet() failed: Success!
Wed Jan 31 18:25:41 2018 : publish_entry SCDSet() failed: Success!
Wed Jan 31 18:25:52 2018 : Modem error; the modem is not responding.
Wed Jan 31 18:25:52 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Wed Jan 31 18:25:52 2018 : Connect script failed
Wed Jan 31 22:53:50 2018 : publish_entry SCDSet() failed: Success!
Wed Jan 31 22:53:50 2018 : publish_entry SCDSet() failed: Success!
Wed Jan 31 22:53:51 2018 : Apple Base Script.ccl Version 3.3
Wed Jan 31 22:54:01 2018 : Modem error; the modem is not responding.
Wed Jan 31 22:54:01 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Wed Jan 31 22:54:01 2018 : Connect script failed
Mon Feb  5 19:23:57 2018 : publish_entry SCDSet() failed: Success!
Mon Feb  5 19:23:57 2018 : publish_entry SCDSet() failed: Success!
Mon Feb  5 19:23:58 2018 : Apple Base Script.ccl Version 3.3
Mon Feb  5 19:24:08 2018 : Modem error; the modem is not responding.
Mon Feb  5 19:24:08 2018 : CCLExit: -6019 (Modem error, modem not responding.)
Mon Feb  5 19:24:08 2018 : Connect script failed
Fri Feb  9 21:08:07 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:08:07 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:08:08 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Feb  9 21:08:08 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","www.plusgsm.pl"
Fri Feb  9 21:08:08 2018 : Dialing: ATD*99***1#
Fri Feb  9 21:08:08 2018 : Waiting for connection
Fri Feb  9 21:08:08 2018 : Connection established
Fri Feb  9 21:08:11 2018 : Serial connection established.
Fri Feb  9 21:08:11 2018 : Using interface ppp0
Fri Feb  9 21:08:11 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Feb  9 21:08:43 2018 : IPCP: timeout sending Config-Requests
Fri Feb  9 21:08:43 2018 : IPV6CP: timeout sending Config-Requests
Fri Feb  9 21:08:43 2018 : Connection terminated.
Fri Feb  9 21:08:52 2018 : Serial link disconnected.
Fri Feb  9 21:09:26 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:09:26 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:09:28 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Feb  9 21:09:28 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","Plus"
Fri Feb  9 21:09:28 2018 : Dialing: ATD*99***1#
Fri Feb  9 21:09:28 2018 : Waiting for connection
Fri Feb  9 21:09:28 2018 : Connection established
Fri Feb  9 21:09:31 2018 : Serial connection established.
Fri Feb  9 21:09:31 2018 : Using interface ppp0
Fri Feb  9 21:09:31 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Feb  9 21:10:02 2018 : IPCP: timeout sending Config-Requests
Fri Feb  9 21:10:02 2018 : IPV6CP: timeout sending Config-Requests
Fri Feb  9 21:10:02 2018 : Connection terminated.
Fri Feb  9 21:10:11 2018 : Serial link disconnected.
Fri Feb  9 21:22:16 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:22:16 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:22:17 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Feb  9 21:22:17 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Fri Feb  9 21:22:17 2018 : Dialing: ATD*99***1#
Fri Feb  9 21:22:17 2018 : Waiting for connection
Fri Feb  9 21:22:17 2018 : Connection established
Fri Feb  9 21:22:20 2018 : Serial connection established.
Fri Feb  9 21:22:20 2018 : Using interface ppp0
Fri Feb  9 21:22:20 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Feb  9 21:22:51 2018 : IPCP: timeout sending Config-Requests
Fri Feb  9 21:22:51 2018 : IPV6CP: timeout sending Config-Requests
Fri Feb  9 21:22:51 2018 : Connection terminated.
Fri Feb  9 21:23:01 2018 : Serial link disconnected.
Fri Feb  9 21:23:28 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:23:28 2018 : publish_entry SCDSet() failed: Success!
Fri Feb  9 21:23:35 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Feb  9 21:23:35 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Fri Feb  9 21:23:35 2018 : Dialing: ATD*99***1#
Fri Feb  9 21:23:35 2018 : Waiting for connection
Fri Feb  9 21:23:35 2018 : Connection established
Fri Feb  9 21:23:38 2018 : Serial connection established.
Fri Feb  9 21:23:38 2018 : Using interface ppp0
Fri Feb  9 21:23:38 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Feb  9 21:24:09 2018 : IPCP: timeout sending Config-Requests
Fri Feb  9 21:24:09 2018 : IPV6CP: timeout sending Config-Requests
Fri Feb  9 21:24:09 2018 : Connection terminated.
Fri Feb  9 21:24:19 2018 : Serial link disconnected.
Sun Mar  4 14:10:13 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:10:13 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:12:18 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sun Mar  4 14:12:18 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Sun Mar  4 14:12:18 2018 : Dialing: ATD*99***1#
Sun Mar  4 14:12:18 2018 : Waiting for connection
Sun Mar  4 14:12:18 2018 : Connection established
Sun Mar  4 14:12:21 2018 : Serial connection established.
Sun Mar  4 14:12:21 2018 : Using interface ppp0
Sun Mar  4 14:12:21 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sun Mar  4 14:12:52 2018 : IPCP: timeout sending Config-Requests
Sun Mar  4 14:12:52 2018 : IPV6CP: timeout sending Config-Requests
Sun Mar  4 14:12:52 2018 : Connection terminated.
Sun Mar  4 14:13:02 2018 : Serial link disconnected.
Sun Mar  4 14:13:22 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:13:22 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:13:23 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sun Mar  4 14:13:23 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Sun Mar  4 14:13:23 2018 : Dialing: ATD*99***1#
Sun Mar  4 14:13:23 2018 : Waiting for connection
Sun Mar  4 14:13:23 2018 : Connection established
Sun Mar  4 14:13:26 2018 : Serial connection established.
Sun Mar  4 14:13:26 2018 : Using interface ppp0
Sun Mar  4 14:13:26 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sun Mar  4 14:13:29 2018 : [DISCONNECT]
Sun Mar  4 14:13:29 2018 : Hangup (SIGHUP)
Sun Mar  4 14:13:29 2018 : Connection terminated.
Sun Mar  4 14:13:39 2018 : Serial link disconnected.
Sun Mar  4 14:19:42 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:19:42 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:19:43 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sun Mar  4 14:19:43 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Sun Mar  4 14:19:43 2018 : Dialing: ATD*99***1#
Sun Mar  4 14:19:43 2018 : Waiting for connection
Sun Mar  4 14:19:43 2018 : Connection established
Sun Mar  4 14:19:46 2018 : Serial connection established.
Sun Mar  4 14:19:46 2018 : Using interface ppp0
Sun Mar  4 14:19:46 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sun Mar  4 14:20:17 2018 : IPCP: timeout sending Config-Requests
Sun Mar  4 14:20:17 2018 : IPV6CP: timeout sending Config-Requests
Sun Mar  4 14:20:17 2018 : Connection terminated.
Sun Mar  4 14:20:27 2018 : Serial link disconnected.
Sun Mar  4 14:20:45 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:20:45 2018 : publish_entry SCDSet() failed: Success!
Sun Mar  4 14:20:46 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sun Mar  4 14:20:46 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Sun Mar  4 14:20:47 2018 : Dialing: ATD*99***1#
Sun Mar  4 14:20:47 2018 : Waiting for connection
Sun Mar  4 14:20:47 2018 : Connection established
Sun Mar  4 14:20:50 2018 : Serial connection established.
Sun Mar  4 14:20:50 2018 : Using interface ppp0
Sun Mar  4 14:20:50 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sun Mar  4 14:20:51 2018 : CHAP authentication succeeded
Sun Mar  4 14:21:21 2018 : IPCP: timeout sending Config-Requests
Sun Mar  4 14:21:21 2018 : IPV6CP: timeout sending Config-Requests
Sun Mar  4 14:21:21 2018 : Connection terminated.
Sun Mar  4 14:21:30 2018 : Serial link disconnected.
Wed Mar  7 20:58:26 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 20:58:26 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 20:58:27 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Wed Mar  7 20:58:27 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Wed Mar  7 20:58:27 2018 : Dialing: ATD*99***1#
Wed Mar  7 20:58:27 2018 : Waiting for connection
Wed Mar  7 20:58:27 2018 : Connection established
Wed Mar  7 20:58:30 2018 : Serial connection established.
Wed Mar  7 20:58:30 2018 : Using interface ppp0
Wed Mar  7 20:58:30 2018 : Connect: ppp0 <--> /dev/cu.wwan
Wed Mar  7 20:59:01 2018 : IPCP: timeout sending Config-Requests
Wed Mar  7 20:59:01 2018 : IPV6CP: timeout sending Config-Requests
Wed Mar  7 20:59:01 2018 : Connection terminated.
Wed Mar  7 20:59:11 2018 : Serial link disconnected.
Wed Mar  7 20:59:27 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 20:59:27 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 20:59:28 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Wed Mar  7 20:59:28 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","plus"
Wed Mar  7 20:59:28 2018 : Dialing: ATD*99***1#
Wed Mar  7 20:59:28 2018 : Waiting for connection
Wed Mar  7 20:59:28 2018 : Connection established
Wed Mar  7 20:59:32 2018 : Serial connection established.
Wed Mar  7 20:59:32 2018 : Using interface ppp0
Wed Mar  7 20:59:32 2018 : Connect: ppp0 <--> /dev/cu.wwan
Wed Mar  7 21:00:03 2018 : IPCP: timeout sending Config-Requests
Wed Mar  7 21:00:03 2018 : IPV6CP: timeout sending Config-Requests
Wed Mar  7 21:00:03 2018 : Connection terminated.
Wed Mar  7 21:00:12 2018 : Serial link disconnected.
Wed Mar  7 21:01:20 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 21:01:20 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 21:01:21 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Wed Mar  7 21:01:21 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","www.plusgsm.pl"
Wed Mar  7 21:01:21 2018 : Dialing: ATD*99***1#
Wed Mar  7 21:01:21 2018 : Waiting for connection
Wed Mar  7 21:01:21 2018 : Connection established
Wed Mar  7 21:01:24 2018 : Serial connection established.
Wed Mar  7 21:01:24 2018 : Using interface ppp0
Wed Mar  7 21:01:24 2018 : Connect: ppp0 <--> /dev/cu.wwan
Wed Mar  7 21:01:55 2018 : IPCP: timeout sending Config-Requests
Wed Mar  7 21:01:55 2018 : IPV6CP: timeout sending Config-Requests
Wed Mar  7 21:01:55 2018 : Connection terminated.
Wed Mar  7 21:02:05 2018 : Serial link disconnected.
Wed Mar  7 21:02:36 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 21:02:36 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 21:02:39 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Wed Mar  7 21:02:39 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Wed Mar  7 21:02:39 2018 : Dialing: ATD*99***1#
Wed Mar  7 21:02:39 2018 : Waiting for connection
Wed Mar  7 21:02:39 2018 : Connection established
Wed Mar  7 21:02:42 2018 : Serial connection established.
Wed Mar  7 21:02:42 2018 : Using interface ppp0
Wed Mar  7 21:02:42 2018 : Connect: ppp0 <--> /dev/cu.wwan
Wed Mar  7 21:03:13 2018 : IPCP: timeout sending Config-Requests
Wed Mar  7 21:03:13 2018 : IPV6CP: timeout sending Config-Requests
Wed Mar  7 21:03:13 2018 : Connection terminated.
Wed Mar  7 21:03:23 2018 : Serial link disconnected.
Wed Mar  7 22:35:08 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 22:35:08 2018 : publish_entry SCDSet() failed: Success!
Wed Mar  7 22:35:12 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Wed Mar  7 22:35:12 2018 : Initializing PDP context: AT+CGDCONT=1,"IP","internet"
Wed Mar  7 22:35:13 2018 : Dialing: ATD*99***1#
Wed Mar  7 22:35:13 2018 : Waiting for connection
Wed Mar  7 22:35:13 2018 : Connection established
Wed Mar  7 22:35:16 2018 : Serial connection established.
Wed Mar  7 22:35:16 2018 : Using interface ppp0
Wed Mar  7 22:35:16 2018 : Connect: ppp0 <--> /dev/cu.wwan
Wed Mar  7 22:35:47 2018 : IPCP: timeout sending Config-Requests
Wed Mar  7 22:35:47 2018 : IPV6CP: timeout sending Config-Requests
Wed Mar  7 22:35:47 2018 : Connection terminated.
Wed Mar  7 22:35:56 2018 : Serial link disconnected.
Fri Mar  9 19:36:40 2018 : publish_entry SCDSet() failed: Success!
Fri Mar  9 19:36:40 2018 : publish_entry SCDSet() failed: Success!
Fri Mar  9 19:36:41 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Mar  9 19:36:41 2018 : Dialing: ATD*99***1#
Fri Mar  9 19:36:41 2018 : Waiting for connection
Fri Mar  9 19:36:41 2018 : Connection established
Fri Mar  9 19:36:44 2018 : Serial connection established.
Fri Mar  9 19:36:44 2018 : Using interface ppp0
Fri Mar  9 19:36:44 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Mar  9 19:37:15 2018 : IPCP: timeout sending Config-Requests
Fri Mar  9 19:37:15 2018 : IPV6CP: timeout sending Config-Requests
Fri Mar  9 19:37:15 2018 : Connection terminated.
Fri Mar  9 19:37:25 2018 : Serial link disconnected.
Fri Mar  9 19:58:54 2018 : publish_entry SCDSet() failed: Success!
Fri Mar  9 19:58:54 2018 : publish_entry SCDSet() failed: Success!
Fri Mar  9 19:58:55 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Fri Mar  9 19:58:55 2018 : Dialing: ATD*99***1#
Fri Mar  9 19:58:55 2018 : Waiting for connection
Fri Mar  9 19:58:55 2018 : Connection established
Fri Mar  9 19:58:58 2018 : Serial connection established.
Fri Mar  9 19:58:58 2018 : Using interface ppp0
Fri Mar  9 19:58:58 2018 : Connect: ppp0 <--> /dev/cu.wwan
Fri Mar  9 19:59:29 2018 : IPCP: timeout sending Config-Requests
Fri Mar  9 19:59:29 2018 : IPV6CP: timeout sending Config-Requests
Fri Mar  9 19:59:29 2018 : Connection terminated.
Fri Mar  9 19:59:39 2018 : Serial link disconnected.
Sat Mar 10 14:51:15 2018 : publish_entry SCDSet() failed: Success!
Sat Mar 10 14:51:15 2018 : publish_entry SCDSet() failed: Success!
Sat Mar 10 14:51:16 2018 : CCLWrite : AT\13
Sat Mar 10 14:51:16 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:51:16 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sat Mar 10 14:51:16 2018 : CCLWrite : ATE0V1&F&D2&C1S0=0\13
Sat Mar 10 14:51:16 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:51:16 2018 : Dialing: ATD*99***1#
Sat Mar 10 14:51:16 2018 : CCLWrite : ATD*99***1#\13
Sat Mar 10 14:51:16 2018 : Waiting for connection
Sat Mar 10 14:51:16 2018 : CCLMatched : CONNECT
Sat Mar 10 14:51:16 2018 : Connection established
Sat Mar 10 14:51:19 2018 : CCLExit: 0
Sat Mar 10 14:51:19 2018 : Serial connection established.
Sat Mar 10 14:51:19 2018 : using link 0
Sat Mar 10 14:51:19 2018 : Using interface ppp0
Sat Mar 10 14:51:19 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sat Mar 10 14:51:20 2018 : sent [LCP ConfReq id=0x1 <asyncmap 0x0> <magic 0x3b96a89d> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : rcvd [LCP ConfReq id=0x0 <asyncmap 0x0> <auth chap MD5> <magic 0x465b0b6f> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : No auth is possible
Sat Mar 10 14:51:20 2018 : lcp_reqci: returning CONFREJ.
Sat Mar 10 14:51:20 2018 : sent [LCP ConfRej id=0x0 <auth chap MD5>]
Sat Mar 10 14:51:20 2018 : rcvd [LCP ConfAck id=0x1 <asyncmap 0x0> <magic 0x3b96a89d> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : rcvd [LCP ConfReq id=0x1 <asyncmap 0x0> <magic 0x465b0b6f> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : lcp_reqci: returning CONFACK.
Sat Mar 10 14:51:20 2018 : sent [LCP ConfAck id=0x1 <asyncmap 0x0> <magic 0x465b0b6f> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:20 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:20 2018 : rcvd [LCP DiscReq id=0x2 magic=0x465b0b6f]
Sat Mar 10 14:51:23 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:23 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:26 2018 : Received protocol dictionaries
Sat Mar 10 14:51:26 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:26 2018 : Received protocol dictionaries
Sat Mar 10 14:51:26 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:29 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:29 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:32 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:32 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:35 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:35 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:38 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:38 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:41 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:41 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:44 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:44 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:47 2018 : sent [iPCP ConfReq id=0x1 <compress VJ 0f 01> <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns3 0.0.0.0>]
Sat Mar 10 14:51:47 2018 : sent [iPV6CP ConfReq id=0x1 <addr fe80::eef4:bbff:fe6d:222c>]
Sat Mar 10 14:51:50 2018 : IPCP: timeout sending Config-Requests
Sat Mar 10 14:51:50 2018 : IPV6CP: timeout sending Config-Requests
Sat Mar 10 14:51:50 2018 : sent [LCP TermReq id=0x2 "No network protocols running"]
Sat Mar 10 14:51:50 2018 : Connection terminated.
Sat Mar 10 14:51:51 2018 : CCLWrite : +++
Sat Mar 10 14:51:59 2018 : CCLWrite : ATH\13
Sat Mar 10 14:51:59 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:52:00 2018 : CCLWrite : AT&F\13
Sat Mar 10 14:52:00 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:52:00 2018 : CCLExit: 0
Sat Mar 10 14:52:00 2018 : Serial link disconnected.





Link to comment
Share on other sites
viking1304 Staff Sergeant

viking1304

Posted
Posted

Hmm...

Sat Mar 10 14:51:15 2018 : publish_entry SCDSet() failed: Success!
Sat Mar 10 14:51:15 2018 : publish_entry SCDSet() failed: Success!
Sat Mar 10 14:51:16 2018 : CCLWrite : AT\13
Sat Mar 10 14:51:16 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:51:16 2018 : Initializing phone: ATE0V1&F&D2&C1S0=0
Sat Mar 10 14:51:16 2018 : CCLWrite : ATE0V1&F&D2&C1S0=0\13
Sat Mar 10 14:51:16 2018 : CCLMatched : OK\13\10
Sat Mar 10 14:51:16 2018 : Dialing: ATD*99***1#
Sat Mar 10 14:51:16 2018 : CCLWrite : ATD*99***1#\13
Sat Mar 10 14:51:16 2018 : Waiting for connection
Sat Mar 10 14:51:16 2018 : CCLMatched : CONNECT
Sat Mar 10 14:51:16 2018 : Connection established
Sat Mar 10 14:51:19 2018 : CCLExit: 0
Sat Mar 10 14:51:19 2018 : Serial connection established.
Sat Mar 10 14:51:19 2018 : using link 0
Sat Mar 10 14:51:19 2018 : Using interface ppp0
Sat Mar 10 14:51:19 2018 : Connect: ppp0 <--> /dev/cu.wwan
Sat Mar 10 14:51:20 2018 : sent [LCP ConfReq id=0x1 <asyncmap 0x0> <magic 0x3b96a89d> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : rcvd [LCP ConfReq id=0x0 <asyncmap 0x0> <auth chap MD5> <magic 0x465b0b6f> <pcomp> <accomp>]
Sat Mar 10 14:51:20 2018 : No auth is possible
Sat Mar 10 14:51:20 2018 : lcp_reqci: returning CONFREJ.
This doesn't look like low power issue to me. I would say that it actually connects, but doesn't pass the protocol negotiation for some reason.

I can see from your previous post that you are using Plus GSM. Have you tried to set your APN, but to left user and password blank as suggested?
APN: plus
Username: left blank
Password: left blank
btw. it's better to attach your log in your message, since some people would not bother to go to download host just to download your log.
Link to comment
Share on other sites
wojciech679 Private First Class

wojciech679

Posted
  • Author
Posted
I set various configuration APN e.g. internet, plus, Plus. Still is the same error. I called to Customer Service my GSM network (Plus GSM).  He told me, that my modem detect correctly my SIM card (WWAN Information / number IMSI), but it isn't logging in to the network, no coverage and perhaps I don't have active modules in my modem (his suggestion).

What do you think about this?



Link to comment
Share on other sites
viking1304 Staff Sergeant

viking1304

Posted
Posted

Let's try to communicate with device itself and check what we will get.



If you device is used you might get a notification that resource is busy and you will not be able to use any of those commands. Since I haven't found a way to release previously used device under macOS I can only suggest you to restart your system and to open Terminal before trying to connect.



Please note that delete doesn't work, so type commands slowly in order to avoid mistakes. If you made any mistake, just press enter and type whole command again.



Restart your system, open Terminal and type:

screen /dev/tty.wwan 115200

You will only get a cursor at top left corner.

Type ATI5 and press Enter. You should get response from your modem. Something like this:

Manufacturer: Sierra Wireless, Incorporated
Model: EM7305
Revision: SWI9X15C_05.05.58.00 r27038 carmd-fwbuild1 2015/03/04 21:30:23
IMEI: 3X3XX605XX20XX2
IMEI SV: 18
FSN: FL5211XX23XX10
+GCAP: +CGSM

OK

Type AT!GSTATUS? and press Enter. You should get status report:

!GSTATUS:
Current Time:  5426             Temperature: 28
Bootup Time:   0                Mode:        ONLINE
System mode:   LTE              PS state:    Attached
LTE band:      B20              LTE bw:      10 MHz
LTE Rx chan:   6300             LTE Tx chan: 24300
EMM state:     Registered       Normal Service
RRC state:     RRC Idle
IMS reg state: No Srv


RSSI (dBm):    -64              Tx Power:    0
RSRP (dBm):    -93              TAC:         2XX5 (1XX73)
RSRQ (dB):     -9               Cell ID:     001XX8X0 (15XX2X2)
SINR (dB):      2.6

OK

What is your Mode? ONLINE, LOW POWER MODE or something else? Based on your PPP log I am 99.99% sure that you will not get LOW POWER MODE, but I want to be sure.

  • Like 1
Link to comment
Share on other sites
wojciech679 Private First Class

wojciech679

Posted
  • Author
Posted
YEEEAH!!! We have it! 00.01% - it was enough not to be right. My modem has mode "LOW POWER MODE"! This is the cause of the problem.
So whats next?


ATI5

Manufacturer: Sierra Wireless, Incorporated

Model: MC8805

Revision: SWI9X15C_05.05.67.00 r31378 CARMD-EV-FRMWR1 2016/03/11 14:58:53

IMEI: 355605054636706

IMEI SV: 21

FSN: FF426601620310

+GCAP: +CGSM,+DS,+ES



OK

AT!GSTATUS?

!GSTATUS:

Current Time:  1179             Temperature: 23

Bootup Time:   0                Mode:        LOW POWER MODE

System mode:   WCDMA            PS state:    Not attached

WCDMA band:    WCDMA 2100

WCDMA channel: 0

GMM (PS) state:NULL             ---

MM (CS) state: NULL             NO IMSI



WCDMA L1 state:L1M_STOPPED      LAC:         0000 (0)

RRC state:   DISCONNECTED       Cell ID:     00000000 (0)

RxM RSSI C0:    ---             RxD RSSI C0:  ---

RxM RSSI C1:    ---             RxD RSSI C1:  ---



OK

Link to comment
Share on other sites
  • Administrators
Hervé Brigadier General

Hervé

Posted
  • Administrators
Posted

See posts #7 and #8 on p1. Basically, the modem needs this so-called magic "DMS Set FCC Auth" command to be set online.

=> https://sigquit.wordpress.com/2015/02/09/dell-branded-sierra-wireless-3g4g-modem-not-online/

=> https://cgit.freedesktop.org/libqmi/commit/?id=22628a69dad6a1c4b0400dacf1c13c48425faf69



As stated in the above articles as well as others you may encounter on the web, there appears to be no other alternative to setting the card to online mode (in Windows, the driver does it transparently). You'll find that several people chose to replace this MC8805-based card by other and less troublesome models.



You'll find useful details on the MC8805 chip here. In particular, you'll probably find more meaningful to know that low power mode = Airplane mode. Now, if you look at table 2-1 on p9, you'll notice references to AT commands related to setting the modem in low power mode. It may well be that setting the values to 1 rather than 0 puts the modem back online:


Link to comment
Share on other sites
  • Administrators
Hervé Brigadier General

Hervé

Posted
  • Administrators
Posted

Indeed, the table shows the W_DISABLE_N input line attached pin 20 (that pin again), so if it's taped, no assertion signal can normally be received on the modem to disable RF module. This is actually stated on p34 of that document:


This being said, we'd need to confirm that MC8805 follows the same pinout (which is highly likely) though there can be no harm in trying masking pin20 anyway. It's not as if it could burst the hosting laptop to flames. Or is it?  :mrgreen: I've not managed to find a copy of the AirPrime MC8805 Product Technical Specification Document & Customer Design Guidelines.



@wojciech679, yes you should be able to Terminal to access the device associated to the USB modem once you've identified it. Other tools such as putty would probably be easier to use in order to issue the relevant AT commands.

Link to comment
Share on other sites

Please sign in to comment

You will be able to leave a comment after signing in



Sign In Now
 Share
Go to topic listing
×
×
  • Create New...
