Bluetooth Firmware Uploader


EMlyDinEsH

Recommended Posts

I did not get my BCM94360CD (with BCM20702A0) to enable HandsOff.

WiFi works OOTB. Bluetooth will *not* be recognized OOTB. Only USB-Tree shows BCM20702A0.



If I install latest BluetoothDevBroadcomInjector.kext Bluetooth is recognized (Yipieh!) but HandsOff is shown as disabled in Systemprofiler.



If I install BTFirmwareUploader.kext instead BluetoothDevBroadcomInjector, the system.log shows these entries after reboot:

12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: ProductID 0x22be, VendorID 0xa5c
12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: Broadcom WiFi/BT combo Bluetooth controller found
12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: Device is Azurewave 4352/4360 combo
12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: Using device specific firmware v14 c5577
12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: Started the upload of firmware (70014 bytes)...
12.02.16 02:25:38,000 kernel[0]: BTFirmwareUploader :: Successfully patched the firmware.
But Bluetooth is not recogized then anymore in Systemprofiler and BCM20702A0 also disappeard from the USB-Tree!



Simple removing BTFirmwareUploader.kext did not help to get the BCM20702A0 recognized again after reboot.

I additionally had to unplug the BCM94360CD from the USB-connector on the mainboard and remove the power-cord from the PC for  a minute.

I verified this behaviour three times!



Any ideas?



Mainboard: GA-Z97M-D3H, Mac OS 10.11.1
