static could be a bad hdmi cable see if wiggling the wire makes it do that.

you quoted your own answer with your question, need to add apfs.efi to clover drivers folder

can you check in security prefpane if you have to allow the kext to load. it would say it right at the first page.

looks like something on the USB bus

you might need shiki plugin for lilu kext to fix final cut issue.

could be you need to reseat something inside the machine like ram or wlan card.

nullcpu kext breaks sleep. if you cant get proper cpu config then you need to also add sleepenabler kext with nullcpu

i am glad your issue is resolved

try osxaptiofixdrv2-64 you might also need emuvariable driver too you can try this clover it should have option to clear nvram Clover_v2.4k_r4308.zip

you can try repairing your volume from osx recovery using disk utility. also if you have trim enabled you might want to turn it off if your drive is now APFS.

maybe try adding patch to clover kexts to patch Comment: Change 15 port limit to 24 in XHCI kext 10.13 PB1 Find: 837D8C10 Name: AppleUSBXHCIPCI Replace: 837D8C1B

for the voodoo issue you probably need voodoohdasettings loader app from here https://sourceforge.net/projects/voodoohda/files/?source=navbarput it in applications and add the app to your startup items in user apple prefpane

do not forget to set the correct permissions on the kext after transferring it over to S/L/E if not it will not load

DPW95 maybe you need to delete the bt preferences in /Library/Preferences or /System/Library/Preferences also maybe you are having usb issues after sleep. compare your ioregistry BT devices before and after a wake.

you could have at least posted the pictures to this forum instead of another forum we do not have access too to see them.or you can ask for help over there.

maybe it is on the I2c bus not ps2.

you can put mach kernel in the missing location or you can configure the chameleon plist to direct it to where the kernel is located lets say it's in root of drive or you manually put it there then in the plist tell chameleon where the kernel is. with clover the issue might be your machine is bios only or you do not have uefi enabled. in that case you have to install clover in legacy mode from a different osx booted volume so that the clover installer can unmount the drive to install the boot files.if your drive has 4k sector offset you might have to reinstall the boot loader a few times for either chameleon or clover to take and make sure also in bios that your sata is set to AHCI. sometimes setting bios to defaults and reseting data to AHCI helps too.

if those acpi errors are on SSDT's you might want to drop them also you can use darkewake=0 flag and clover installer RC scripts options

if your using legacy boot loader install then you might have to reinstall the boot loader from a different osx volume or disk especially if you have a HDD/SSD that has a 4k sector offset so that the drive can be unmounted to wright the new boot sector files. also if it puts the EFI on the root of the osx volume you just installed too you need to move it to the real EFI volume so that clover can function properly if using clover. clover cannot wright to HFS so some things might night work correctly like making dumps or logs and sometimes nvram if using emuvariable driver but the real EFI volume is formatted fat32 so clover will function.

it might still have the older versions in your prelinked cache you need to rebuild caches when removing kexts from SLE or LE to flush them out same goes for adding new kexts to those locations

is it showing up on your usb bus? also i have it in clover/kexts/other not S/L/E since it needs to be injected before the kext in S/L/E loads.

you can always try https://sourceforge.net/projects/voodoohda/ you can adjust the info.plist in the kext if you have issues.

you have AHCI set for sata in bios right?

im running my DW1550 on 10.13.2 with this injector I compiled only BRCMInjector.kext.zip

well try install to it that way then put it back into the machine.
